Letkut ja liitokset, Lisävarusteet

Letkunkiristimet

Valitse malli

Kuvaus

The hose is the conveying line of the source extraction installation.

The demands placed on the suction hose are:

wear resistance
low weight and flexibility
not affected by extremes of temperatures
crushproof
does not give static electric shocks

When long suction hoses have to be used their diameter should progressively increase from the suction casing, with the smallest hose nearest the suction casing not exceeding 2–3 m length. Coupling is carried out with external couplings which are easy to use.

**Technical Data**
Description	dmin / dmax	Part No
Hose clamp	.3’’-.6’’/8-14 mm	4027
Hose clamp	.4’’-.7’’/11-17 mm	4028
Hose clamp	.6’’-.9’’/15-24 mm	4146
Hose clamp	1’’-1.5’’/26-38 mm	4197
Hose clamp	1.7’’-2.2’’/44-56 mm	4075
Hose clamp	2’’-2.6’’/50-65 mm	4219
Hose clamp	2.3’’-3’’/58-75 mm	4002
Hose clamp	2.7’’-3.3’’/68-85 mm	3002
Hose clamp	3’’-3.7’’/77-95 mm	4090
Hose clamp	3.4’’-4.4’’/87-112 mm	4310
Hose clamp	4.1’’-5.4’’/104-138 mm	4138
Hose clamp	5.1’’-6.5’’/130-165 mm	4040
Hose clamp	5.9’’-7.1’’/150-180 mm	4137
Hose clamp	7.9’’-9.1’’/200-231 mm	4464
Hose clamp	8.9’’-10.1’’?/226-256 mm	4102
